4K 3840X2160 35X USB3.0 HDMI SDI PTZ Video Conference Camera will be Release ※ 3840X2160P30 ULTRA HD VIDEO RESOLUTION ※ Adopts most advanced ISP, 1/1.7" inch 12MP sensor, provide Ultra high definition crystal clear image with full details ※ 4K WIDE ANGLE OPTICAL LENS:35X OTPICAL ZOOM,60 DEGREEE FIELD OF VIEW ※ 4K VIDEO OVER IP, AND SUPPORT H.264,H.265 ENCODING ※ Meanwhile, HDMI, SDI, USB outputs as well, fit for different application ※ POE SUPPORTED ※ One single cable allows video transmission, camera control as well as power supply ※ HIGH PRECISE MOTOR POSITIONING ※ -170° to +170° pan rotation, -30° - 90° tilt rotation, quiet & smooth mechanism movement, accurate & fast focus, capture every details in whole space ※ STANARD SONY VISCA OVER SERIES AND SONY VISCA OVER IP SUPPORTED

Now our PATC-F series dual payload thermal ptz camrea is a maritime standard ruggedized thermal vision system, housed with aluminum, the camera is anti-corrosive and IP67 rated, enabling it to work properly even in tough sea environment. The camera incorporates a 640x480/380x288 uncooled thermal core and a 20x day light camera, added its radar tracking, digital stabilization,25hz/30hz continuous thermal imaging capability, easy control with maritime keyboard controller, making the camera a perfect system to assist mariners to safely navigate. Radar Tracking(Optional) PATC-F Series camera receives, reads, analyzes NMEA0186 strings from Radar and manages algorithm calculation from current vessel position to the target(s), finally camera moves to view the targets actively. Video Tracking(Optional) The function allows a target lock on the video image and allows tracking so the camera keeps pointed on it. Ethernet & Serial Control Via Keyboard Controller Optional maritime keyboard controllers have both Ethernet and RS485 interfaces to control the camera, the controller is used to pan tilt and zoom the camera, operate the camera functions with its buttons and OSD menu, and also move the camera into or out of stanby mode. PATC F Camera Application
